Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter
Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter

Srne Solar 14kw 16kw 18kw Hybrid Inverter WIFI Solar Pure Sine Hybrid Inverter UL 3 Mppt Split Three Phase Solar Power Inverter

Get a Quote
Product Description
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-2
Products Description
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-3
Specification
MODEL AC Input/Output Data
HESP48140UH3
HESP48160UH3
HESP48180UH3
Rated AC Input/Output Active Power
14000W
16000W
18000W
Max. AC Input/Output Apparent Power
15400VA
17600VA
19800VA
Rated AC Input/Output Current
44.5A/38.8A
50A/44.5A
55.5A/50A
Max. AC Input/Output Current
44.5A/38.8A
50A/44.5A
55.5A/50A
Peak Power (off-grid)
28000VA
32000VA
36000VA
Power Factor Adjustment Range
0.8 leading to 0.8 lagging
Rated Input/Output Voltage/Range
120/208V 0.85Un-1.1Un
Rated Input/Output Grid Frequency/Range
60Hz/40Hz-70Hz
Grid Connection Form
3L+N+PE
THD
<3% (of nominal power)
Battery Input Data
Battery Type
Lead-Acid Batteries / Lithium Batteries / User-defined
Number of Battery Input
2
Battery Voltage Range
40V-60V
Max. Grid/Generator Charging Current
300A
330A
350A
Max. Hybrid Charging Current
300A
330A
350A
Max. Discharging Current
300A
330A
350A
Charging Strategy for Li-ionBattery
Self-adaption to BMS
PV Input Data
No. Of MPPT Trackers
3
No. of Strings MPPT Tracker
2+2+2
Max. PV Access Power
28000W
32000W
36000W
Max. PV Input Power
22400W
25600W
28800W
Rated PV Input Voltage
450V
Max. PV Input Voltage
600V
Start-up Voltage
120V
Max. PV Input Current
40A/40A/40A
Max. Input Short-Circuit Current
50A/50A/50A
MPPT Voltage Range
120V-500V
Grid/Generator Input
Input Voltage Range
Phase voltage: 90V-140V, line voltage: 156V-243V
Input Frequency Range
40Hz-70Hz
Max. Bypass Overload Current (Grid)
200A
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-4
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-5
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-6
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-7
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-8
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-9
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-10
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-11
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-12
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-13
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-14
product srne solar 14kw 16kw 18kw hybrid inverter wifi solar pure sine hybrid inverter ul 3 mppt split three phase solar power inverter-15
