Products Description

Specification

MODEL AC Input/Output Data	HESP48140UH3	HESP48160UH3	HESP48180UH3
Rated AC Input/Output Active Power	14000W	16000W	18000W
Max. AC Input/Output Apparent Power	15400VA	17600VA	19800VA
Rated AC Input/Output Current	44.5A/38.8A	50A/44.5A	55.5A/50A
Max. AC Input/Output Current	44.5A/38.8A	50A/44.5A	55.5A/50A
Peak Power (off-grid)	28000VA	32000VA	36000VA
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
Rated Input/Output Voltage/Range	120/208V 0.85Un-1.1Un
Rated Input/Output Grid Frequency/Range	60Hz/40Hz-70Hz
Grid Connection Form	3L+N+PE
THD	<3% (of nominal power)
Battery Input Data
Battery Type	Lead-Acid Batteries / Lithium Batteries / User-defined
Number of Battery Input	2
Battery Voltage Range	40V-60V
Max. Grid/Generator Charging Current	300A	330A	350A
Max. Hybrid Charging Current	300A	330A	350A
Max. Discharging Current	300A	330A	350A
Charging Strategy for Li-ionBattery	Self-adaption to BMS
PV Input Data
No. Of MPPT Trackers	3
No. of Strings MPPT Tracker	2+2+2
Max. PV Access Power	28000W	32000W	36000W
Max. PV Input Power	22400W	25600W	28800W
Rated PV Input Voltage	450V
Max. PV Input Voltage	600V
Start-up Voltage	120V
Max. PV Input Current	40A/40A/40A
Max. Input Short-Circuit Current	50A/50A/50A
MPPT Voltage Range	120V-500V
Grid/Generator Input
Input Voltage Range	Phase voltage: 90V-140V, line voltage: 156V-243V
Input Frequency Range	40Hz-70Hz
Max. Bypass Overload Current (Grid)	200A
