Good Price REVO HM Series 4kw 6kw 8kw 230V Single Phase Hybrid on & Off Grid Energy Storage Inverter 50/60 hz 24V 48V BATTERY, China Good Price REVO HM Series 4kw 6kw 8kw 230V Single Phase Hybrid on & Off Grid Energy Storage Inverter 50/60 hz 24V 48V BATTERY Manufacturers, Suppliers, Factory - Sichuan Grantech New Energy Technology Co.,Ltd.

Technical Specification	REVO HM series
Rated Power	4000VA/4000w	6000VA/6000W
AC INPUT
ACVoltage	230VAC
Voltage Range	170-280VAC(For Personal Computers);90-280 VAC(For Home Appliances)
Frequency Range	50/60Hz(Auto sensing)
AC OUTPUT
Surge Power	8000VA	12000VA
AC Voltage Regulation(Battery Mode)	230VAC±5%
Rated frequency	50/60Hz
Efficiency (Peak)	93%
Transfer Time	10ms(For Personal Computers);20ms(For Home Appliances)
BATTERY
Battery Voltage	24VDC 48VDC
Floating Charge Voltage	27VDC 54VDC
Overcharge Protection	33VDC 63VDC
Battery type	Lithium/Lead-acid
SOLAR CHARGER&AC CHARGER
Maximum PVArray Open Voltage(V)	500VDC
Maximum PV Array Power	5000w 7000W
MPPT voltage range(V)	60~450VDC
Maximum input current	27A
MPPT tracker/strings	1
Maximum solar charge current	120A
Maximum AC charge current	100A
Maximum charge current	120A
PROTECTION&FEATURE
AC overcurrent	Yes
AC overvoltage	Yes
Over temperature protection	Yes
Smart load management	Yes
On Grid	Yes
Parallel Function	Max6 units
GENERAL PARAMETERS

Operation temperature	-10℃~50℃

Relative humidity	5%~95%(Non-condensing)
Altitude	(2000m Derating)
Dimensions DxWxH(mm)	466316127
Net Weight(KG)	8.8 10.1
DISPLAY AND COMMUNICATION
Display	Touch buttons
Interface	Standard:RS232,USB;CAN&RS485;Optional:WiFi,Bluetooth
Safety standard	EN/IEC62109-1,EN/IEC62109-2
