120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker

120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker

Get a Quote
Product Description
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker factory
Feature
Specification
Rated Output Power
12kW
Peak Power
18kVA
MPPT Quantity
Dual MPPT
Max PV Input Power
24kW (12kW+12kW)
Max PV Input Voltage
500V DC
Max Charging Current
250A
Battery Voltage
48V (51.2V nominal)
Parallel Capability
Up to 6 units
Output Voltage
120/240V Split Phase
Transfer Time
10ms
Efficiency
>91%
Communication
USB / RS485 / WiFi / GPRS
Battery Type
Lithium / Lead Acid
Cooling
Intelligent Fan Cooling
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker factory
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker factory
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker details
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker details
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker manufacture
Company Profile
SICHUAN GRANDTECH NEW ENERGY TECHNOLOGY CO. LTD. is a professional supplier of solar energy storage industry. We are engaged in manufacturing and marketing of solar inverter and storage energy battery. Through vast experience, we established a list of certified manufacturers that have all the relevant ICE, UL, ISO and other certifications required as well as proven commitment to quality. Supplying high quality products is the foundation of our company. Our plant has a strict quality control system and is equipped with state-of-the-art process and production facilities.
All of our efforts during manufacturing are aimed at provided the Customer with the peace of mind that when the equipment arrives on location, it is ready to go to work, and it will perform reliably. We strive to provide our clients with high quality products, good service, timely delivery and competitive prices and look forward to cooperating with you.
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker details
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker factory
120V 240v 12KW Hybrid Inverter Split Phase GES48120M250 -500XP_Plus Inverter with Wifi and Circuit Breaker details
FAQ
Q1: What is the rated power of the SPI-10K-U?
A: It provides 10,000W rated power and up to 20,000W peak power.
Q2: What battery types are supported?
A: It supports 48V Li-ion and lead-acid batteries, with BMS communication available.
Q3: How many MPPT trackers does it have?
A: It features dual MPPT with 5,500W + 5,500W PV input capacity.
Q4: What is the maximum charging current?
A: The maximum charging current is up to 200A.
Q5: Does it support monitoring?
A: Yes, it supports RS485 / CAN / USB, and optional WiFi or GPRS remote monitoring.
Q6: Is it suitable for outdoor installation?
A: No, it is IP20 rated and designed for indoor installation only.
×
